XTZ - InWall OnWall E-IW62


Slimmed HiFi speakers for wall mounting and built-in installation

The E-IW62 is a versatile 3-way in-wall LCR speaker designed for purpose-built home cinemas whether its mounted flush into a shallow baffle wall behind an acoustically transparent screen or installed on-wall in a clean modern living room.

It delivers the immersive wide-stage sound youd expect from a much larger enclosure while its compact sealed cabinet disappears into the room visually and acoustically.

Because the product has a job inside the room.

Discreet 117 mm on-wall installation

1" Al/Mg tweeter for clear, controlled treble

Handles high SPL with clean, dynamic playback

Compact size, cinema-grade performance

All kevlar drivers for fast, detailed dynamics

Extends to 80 Hz with clean, controlled bass

Technical Specifications
Construction Type

3-way In-wall / On-wall speaker

Frequency Response

80 - 30.000 Hz (+/- 3dB)

Tweeter Driver

1 x 25 mm (1 inch) aluminum-magnesium alloy dome

Midrange Woofer Driver

2 x 100 mm (4 inch) Kevlar composite cone

Woofer Driver

2 x 165 mm (6.5 inch) Kevlar composite cone

Nominal Impedance

4 Ohm

Sensitivity

92 dB (2,83 V/1 m)

Power Handling

300 W Short term, 150 W Long term

Dimensions

220 x 740 x 117 mm / 8.7 x 29.1 x 4.6"

Weight

13 kg / 28.7 lbs

Available Colours

Matte black
